2Sets Electrolytic Capacitor and Schottky Diode for LED emblem

Features of the Electrolytic Capacitor and Schottky Diode

• You can use an electrolytic capacitor and a Schottky diode before the VW LED emblem. A customer shared their connection setup, which you can check as a reference.
• Using an electrolytic capacitor and a Schottky diode can help smooth out the electricity supply, reducing flickering and ensuring stable operation of the LED emblem.

How to Connect the Electrolytic Capacitor and Schottky Diode ？
